Hot Dipped Galvanized Crowd Control Barriers For Sale, Available any Size Customized

ITEM SPECIFICATIONS

Product Name	Portable Temporary Fence, Pedestrian Barricades, Crowd Control Barriers
Applications	Secure construction sites, major public, festival, events, etc.
Material	Pre-galvanized steel tube
Panel Size	1.1mx2.1m, 1.1mx2.2m, 1.1mx2.5m, customized supported
Frame Tube Diameter	25mm, 32mm, 38mm, 42mm, 48mm
Frame Thickness	1.5mm, 1.8mm, 2.0mm
Vertical Bar Diameter	16mm, 20mm, 8mm, 6mm
Vertical Bar Thickness	1.0mm, 1.2mm, 1.5mm
Vertical Bar Spacing	60mm, 100mm, 120mm, 190mm, 200mm
Base Styles	Flat, Bridge, Triangle
Welding Technology	Picket inserted into frame before welded, saddle cut welded frame for greater strength
Surface Treatment	Multi-layer protection powder coated *
Color	Various colours available

* Zinc-rich phosphate pre-treatment ensure superior adhesion between the base material and coating, while epoxy primer coating cover all welds and cut edges for strong anti-corrosion and anti-impact, together with AkzoNobel top coating realize exceptional weather resistance with various colors available.

PRODUCTION PROCESS

⒈ Automated Cutting, Punching & Drilling with high precision	⒉ Zinc-rich Phosphating Pre-treatment enhance the adhesion
⒊ Saddle cut welded frame for greater strength	⒋ Multi-layer Protection Powder Coated with AkzoNobel
⒌ Detachable feets for efficient transportation and storage	⒍ Pallet Packing with plastic/bubble cushion protection

FINISHED PRODUCT & PACKING

Detachable feet design maximize the space usage while transportation and storage.

Outside perimeter (mainframe) is made of 38mm diameter galvanized steel tubing, minimum 1.6mm thickness(after coating). The outer frame is a single length of tubing without welds or deformation. The pipe is bent at right angles with a minimum of smooth deformation. Horizontal and vertical bars are at right angles to the overall frame.

Grill: 21 equally-spaced bars inside vertical members, made of 13mm out diameter galvanized steel tubing, minimum 1.2mm(after coating),21 interior bars are 98mm apart, O.D. to O.D.

Locking: Male-Female interlocking ends. Units join and unlock at one position (30 degrees). The male interlocking device is a minimum 16mm diameter rod welded through mainframe at both ends. Male/Female connections have enough clearance to allow for uneven ground, a minimum of 13mm on top and bottom when connected.

Feet: bridge foot detachable

Bridge foot detachable model crowd control barrier(Standard specifications) :

Overall Length: 2600mm(2550when interlocked) or as stipulated
Overall Height: 1100mm or as stipulated
Weight: 19kgs ± 1kgs
Material: Steel tube.

Finish: Entire panel is hot-dip zinc-galvanized after welding (not spraying, not use galvanized tube welding then spraying since on welded points). Every barrier is filed after galvanizing so that burrs from galvanizing are filed smooth and there are no sharp points.

Another finish:
powder-coated black, powder-coated orange or another colour.

Warranty: above 10-year warranty against hot dip galvanised finishing, above 3 years for powder coating.
